SyFlex pump series

SyFlex pump series


  • Max. capacity: 100 m3/hr
  • Max. pressure: 15 bar



This series of positive displacement pumps are mainly used for those applications where a fixed or variable capacity is required.

Depending on the liquid to be pumped, the pumps are available with different hose materials, including natural rubber, food grade, nitrile, hypalon, silicone or EPDM. The connections are also available in various materials including stainless steel AISI 316, PVC, polypropylene, PVDF or Titanium.

The pumps can be supplied with various connections including hose tails, BSP threaded connections, DIN flanged connections, threaded connections according to DIN 11851, clamp connections, etc.

The speed of the pumps to be determined is entirely dependent on the desired capacity in combination with the temperature of the liquid, the desired pressure, the desired vacuum and the number of operating hours.

The pumps are supplied with a fixed capacity based on a gearbox that is available in various gear ratios or a variable capacity obtained by a mechanical variator or a frequency converter.

The pumps are equipped with shoes and a glycerin-filled pump housing.


  • Cast iron
  • Stainless steel AISI304
  • PVC
  • Stainless steel AISI 316
